ZXLD1101
PACKAGE OUTLINE - TSOT23-5
Controlling dimensions are in millimeters. Approximate conversions are given in inches
PACKAGE DIMENSIONS
DIM
Millimeters
Inches
DIM
Millimeters
Inches
Min
Max
Min
Max
Min
Max
Min
Max
A
A1
A2
-
0.01
0.84
1.00
0.10
0.90
-
0.0003
0.0330
0.0393
0.0039
0.0354
E1
e
e1
1.60 BSC
0.95 BSC
1.90 BSC
0.062 BSC
0.0037 BSC
0.074 BSC
b
0.30
0.45
0.0118
0.0177
L
0.30
0.50
0.0118
0.0196
c
0.12
0.20
0.0047
0.0078
L2
0.25 BSC
0.010 BSC
D
E
2.90 BSC
2.80 BSC
0.114 BSC
0.110 BSC
a°
-
4°
-
12°
-
4°
-
12°
-
